MZ73211B Single row horizontal directional multiple drilling machine

FOB Reference Price:Get Latest Price
US $2,500-2,700 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DELILAI
Model Number:
MZ73211B
After-sales Service Provided:
Engineers available to service machinery overseas
Max drill diameter:
35 mm
Depth of drilled holes:
60 mm
number of spindles:
21*1
Vertical spindle heads:
130-3500 mm
Spindle speed:
2840 r/min
Motor power:
1.5 kw
Air pressure:
0.5-0.8 Mpa
Over size:
2000*1200*1500 mm
SupplyAbility
SupplyAbility:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard package
Port
Qingdao
Lead Time :
within 20 days after payment
Product Description

Factory direct wholesale MULTIPLE DRILLING MACHINE

Technical Specification
MZ73211A
MZ73211B
Max diameter of holes/mm
35
35
Depth of drilled holes/mm
0-60
60
Number of spindles
21
21*1
Center distance between spindles/mm
32
Max dimensions of piece to be drilled/mm
2500*920*70
Rotation of spindle/r/min
2840
2840
Total power
1.5
1.5
Air pressure/Mpa
0.5-0.8
0.6-0.8
Gas consumption of drilling 10 panels per minute/L/min
5 approximately
Over size/mm
1900*2600*1300
2000*1200*1500
Weight of the whole machine/kg
480
Height of working plat form off ground/mm
900
Packing size/mm
1100*1300*1400
Vertical spindle heads/mm
130-3500
