MZ73212A Double row horizontal directional multiple drilling machine

FOB Reference Price:Get Latest Price
US $3,200-3,400 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
DELILAI
Model Number:
MZ73212A
After-sales Service Provided:
Engineers available to service machinery overseas
Max diameter of holes:
35 mm
Depth of drilled holes:
0-60 mm
Number of spindles:
21*2
Center distance between spindles:
32 mm
Max dimension of piece to be drilled:
2500*920*70 mm
Rotation of spindle:
2840 r/min
Total power motor:
3.0 kw
Air pressure:
0.5-0.8 Mpa
Weight:
680 kgs
Machine size:
1900*2600*1600 mm
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
standard package
Port
Qingdao
Lead Time :
within 20 days after payment
Product Description

Factory direct wholesale MULTIPLE DRILLING MACHINE

Technical Specification
MZ73212A
MZ73212B
Max drill diameter
35 mm
35mm
Depth of drilled holes
0-60 mm
0-60 mm
Number of spindles
21*2
21*2
Center distance between spindles
32 mm
Max dimensions of piece to be drilled
2500*920*70 mm
Rotation of spindle
2840 r/min
2840 r/min
Total power
3 kw
3 kw
Air pressure
0.5-0.8 Mpa
0.6-0.8 Mpa
Gas consumption of drilling 10 panels per minute
10L/min approximately
Weight of the whole machine
680 kg
Height of working plat form off ground
900 mm
Suitable voltage
380V
Max distance of the two longitudinal heads
380 mm
Min distance of the two longitudinal heads
0 mm
Packing size
1100*1300*1700 mm
Over size
1900*2600*1600 mm
2400*1200*1500 mm
Vertical spindle heads
130-3500 mm
